TSC TDM Series 3-Inch Performance Mobile Printer

TSC Printers

The TDM Series has a tough, palm-sized design for convenient printing on the go, lasting over 42 hours on a single battery charge.


Report incorrect or inappropriate product information.

Rugged Palm-Sized Design
The TDM Series is built to withstand tough conditions, passing a 1.8-meter drop test without a protective case, and a 2.5-meter drop test with a protective case. It meets MIL-STD-810G military standards for drop protection and has an IP54 rating for dust and water resistance with an optional protective case.

Support for Various Media Widths
The TDM-30 features an adjustable media hanger with a label fixing tab, supporting media widths from 20 mm to 70 mm. It can print on various media types, including receipts, labels, and linerless printing. The media spacer is easy to install and can be customized for specific media widths, with a black mark sensor and an optional gap sensor (TDM-30 only) for versatile media handling.

Self-Diagnostic TPH Care Mechanism
The TSC TPH Care Mechanism uses auto-detection to monitor the printhead’s health in real-time. It detects defective dots during printing, helping maintain high print quality and reduce consumable waste for cost-efficiency.

Smart Battery with TSC Printer Management
With the TSC Battery Management System (BMS), users can monitor battery performance, usage history, charging cycles, and health status. The system’s user-friendly interface shows real-time battery capacity, helping ensure a full shift without downtime.

Integrated Software Pack
TSC provides an advanced software package that supports custom label creation across different platforms. The TDM Series is compatible with OPOS for POS applications and supports CPCL and ESC-POS printer languages. The new iOS and Android app allows users to configure printers, check status, and troubleshoot on the go. Web print functionality also supports direct printing from browser-based applications.

Multiple Connectivity Options
The TDM Series supports USB 2.0, MFi Bluetooth 5.0, and a passive NFC tag for easy one-touch connection, as well as USB 2.0 and 802.11 a/b/g/n Wi-Fi with Bluetooth 4.2 and passive NFC tag.

Categories: , Tags: Barcode printer, mobile printer, TDM Series, TSC TDM Series 3-Inch Performance Mobile Printer
Brand

  • 203 dpi (8 dots/mm)
  • Direct thermal only
  • LCD with buttons
  • Hardwire Connectivity: USB
  • Bluetooth MFi, Wi-Fi with Bluetooth
  • TSC Console
  • Mobile
  • Up to 4 ips (102 mm/s)
  • 2.83″ (72 mm)
  • 110″ (2,794 mm)
  • 32 MB SDRAM
  • 16 MB
Media Specifications
  • 1.57″ (40 mm) OD
  • 3.15″ (80 mm) with media hanger: 0.79″ (20 mm) and 2.75″ (70 mm) (user option.
  • Plastic
  • TSPL-EZC or ESC-POS.

    Media Type

  • Reflective sensor model: receipt paper, bline receipt paper (black mark on printing side) & selected label
  • Transmissive sensor model: receipt paper, bline receipt paper (black mark on printing side or backside) & label with gap
  • 1″ (25.4 mm)
